AUDIO AND VIDEO FEATURES
- DTS-ES™ Discrete/Matrix, DTS Neo:6®, DTS 96/24™, Dolby® Digital EX™
Decoding
- DTS Surround Sensation® Speaker Technology
- H.C.P.S. (High Current Power Supply) Massive High Power Transformer
- 192 kHz/24-Bit DACs for All Channels
- Advanced 32-Bit Processing DSP Chip
- 4 Digital Inputs (2 Optical and 2 Coaxial)
- Front-Panel Auxiliary A/V Input (for Camcorders, Game Consoles, etc.)
- HDTV-Capable (720p/1080i) Component Video Switching (2 Inputs and 1
Output)
- Optimum Gain Volume Control Circuitry
- WRAT (Wide Range Amplifier Technology)
- Music Optimizer™ for Compressed Digital Music Files
- Theater-Dimensional Virtual Surround Function
- CinemaFILTER™
- RIHD (Remote Interactive over HDMI) for System Control
- A-Form Listening Mode Memory
- Double Bass Function
- Pure Audio Mode
- Direct Mode
- Crossover Adjustment (40/50/60/80/100/120/150/200 Hz)
- A/V Sync Control Function (Up to 100 ms in 20 ms Steps)
- Subwoofer Pre Out
- Banana Plug-Compatible Speaker Posts (Except Zone 2)
- Color-Coded Speaker Terminals
- RDS (PS/RT/PTY/TP)
- 40 FM/AM Radio Presets
- Compatible with RI (Remote Interactive) Dock for the iPod
- Preprogrammed RI (Remote Interactive) Remote Control
ADVANCED FEATURES
- DTS-HD Master Audio™, DTS-HD High Resolution Audio™, DTS-HD Express,
Dolby® TrueHD, Dolby® Digital Plus, Dolby® Pro Logic® IIz Decoding
- HDMI™ Version 1.3a to Support Deep Color™, x.v.Color™, LipSync, Dolby
TrueHD, DTS-HD Master Audio, DVD-Audio, Super Audio CD, and CEC
- HDMI Audio and Video Processing (1080p; 4 Inputs and 1 Output)
- HDTV-Capable HDMI Video Switching
- Audyssey 2EQ™ to Correct Room Acoustic Problems
- Audyssey Dynamic Volume™ to Maintain Optimal Listening Level and
Dynamic Range
- Audyssey Dynamic EQ™ for Loudness Correction
- Powered Zone 2 and Zone 2 Line-Out for Playback in Another Room
(Separate Source)
- Bi-Amping Capability for Music and Movie Sound Effects
- 4 DSP Modes for Gaming: Rock, Sports, Action, and Role Playing Game
(RPG)
- Universal Port for Single-Cable Connection
- Front-Panel Audio Input for Portable Devices
GENERAL SPECIFICATIONS
- 160 W/Ch at 6 Ohms, 1 kHz, 1 Channel Driven, JEITA
- 130 W/Ch at 6 Ohms, 1 kHz, 1 Channel Driven, IEC
- Frequency Response: 5 Hz–100 kHz (+1 dB, -3 dB)
- WHD: 435 x 151.5 x 329 mm
- Weight: 9.7 kg |
