Preamplifier section | | Input impedance ( Balanced input ) | 47Kohm | Maximum input level | 10 Volt RMS | Noise floor ( 1Vrms, 20 - 20 kHz, balanced) | -135 dB | THD + N (1Vrms, 20 - 20 kHz, balanced) | <0.004% | Gain (Balanced) | 0 dB | | | Amplifier section | | Output Impedance | < 0,02 Ohm | Frequency response | 1 – 150 kHz | Channel separation | > 120 dB | THD ( 20 - 20 kHz) | < 0.004% | Maximum peak current | >100A | Damping factor 8 ohm load | >350 | I Input sensitivity 120W output | 1.3Vrms | Input sensitivity HT 120W output | 1Vrms | Gain HT Input | x36 (31 dB) | Rated output power | | 8 ohms | 2 x 125 W | 4 ohms | 2 x 200 W | 2 ohms | 2 x 370 W | Power consumption | 110 W | Standby | 1W | (no load or signal) | | | | Dimensions | | Width | 470 mm / 18.3 inches | Depth ( with a speaker terminals) | 430 mm / 16,9 inches | Height | 128 mm / 5 inches | Weight | 20,5 Kg / 45 lbs. |
|
|
