[Á¦Ç°»ç¾ç]
- Power: 120 Watts RMS per channel into 8 Ohms. Both channels driven
from 20Hz to 20kHz at less than 0.1% total harmonic distortion.
- Frequency Response: 20Hz to 20kHz ¡¾ 0.2dB. 0dB at 0Hz and -3dB at
70kHz.
- Distortion: Typically <0.05% THD at rated power. 0.1% THD &
IM worst case prior to clipping.
- Current Output: 20A short duration p
- eak per channel. Fuse protected.
- Slewing: 50V/us
- Hum & Noise: 90dB below rated output 20Hz to 20kHz unweighted.
- Input Sensitivity: 290mV RMS for rated output at 1kHz.
- Input Impedance: 47k Ohms.
- Input Overload: 5V RMS
- Rated Pre Out Level: 1.5V RMS into 47k Ohms or higher.
- Pre Out Source Impedance: Typically 1.5k Ohms.
- Pre Out Minimum Recommended Load: 47k Ohms
- Tape Output Level: Unity Gain at 200mV. Tape loop muting at 5V RMS
input.
- Dimensions: Height 105mm (4'), Width 450mm (17.75'), Depth
400mm (15.75'), Weight 10kg (22lb)
|
|
|
2,600,000¿ø
|
750,000¿ø
|
2,900,000¿ø
|
21,000,000¿ø
|
|
