- Type : Solid State
- Configuration Dual-Mono / Fully Balanced
- Power supply Transformers 2 x 150VA(audio); 1 x 10VA(controller)
- Power Supply Capacitance 70,000
- Circuit Topology Open Loop
- Balance inputs (XLR) 3 pairs
- Single-ended inputs (RCA) 4 pairs
- input impedance 11,000 Ohms
- input Sensitivity 200mV - 4.0V RMS
- Monitor Loop 1
- Balanced Outputs (XLR) 2 pairs
- Single-Ended Outputs (RCA) 2 pairs (variable & fixed)
- Output Impedance 50 Ohms
- Volume Steps 1 db from 0-30 and 0.1db from 30-80
- Gain Control M-Ray (fully discrete R-2R)
- Gain 9db
- Signal -to-noise Ratio (20Hz - 20KHz) 130 db
- Maximum Output Voltage - XLR 12 Volts
- Maximum Output Voltage - RCA 6 Volts
- Frequency Response 5Hz - 100KHz (+0 / -0.1db)
- Crosstalk @ 1KHz - 130db
- IMD unmeasurable
- THD(20Hz - 20KHz) 0.002%
- 12 Volt Trigger Output Operation
- Direct Logic (0V=off, 12V=on) using a 3.5mm mono microphone jack with
an input impedance of 1000 Ohms and current requirement of 12mA
- SimLink Port 1 input + 1 output each on 1/8' mini-jack
- Rs-232 Port 9-pin female DB connector
- IR input 1/8' mini-jack
- Remote Control All-Aluminum Full Function
- Display Type 8 character dot matrix LED
- Power Consumption @ idle TBA
- Fuse Replacement - 230V 0.5A short slow blow
- Dimensions - Preamp (WxHxD) 18.75 x 4 x 16.5 in.
- Dimensions - Controller / Power Supply 18.75 x 5.5 x 16.5 in.
- Shipping Weight 74lbs / 33 Kgs
|
|
|
|
